RSO Part 2

Friul should consider branching out. Check out the what a fine bracelet these RSO tracks make, modeled here by my lovely wife Ilene.

Closer inspection reveals why some of the pins broke after I assembled the first run of track. The nub you see in the photo at right is enough to wedge the adjoining link causing it to pull on the pin, shearing it off. Before assembling the second run I filed any nubs off.

The shapes stamped into the back of the cab should also show on the inside, as in this close up from a walkaround at the Military Models website in New Zealand. I edited the picture to indicate the stamped shapes. This particular walkaround is great because the vehicle is painted white and partially disassembled, making details more visible.

I made the matching raised areas in the back of the cab by fitting sheet styrene into the depressions. First I taped a piece of strip styrene into the depression running around the lower part. I bent the strip to get it to go around the corners.

Once I had the styrene shape formed, I simply peeled off the tape and the styrene with it.

Next I put it into the cab and cemented it in place, carefully peeling off the tape.

The rectangular depressions on either side of the rear window have sheet styrene cut to fit...

...which is then transferred to the inside to form the raised areas, then cemented in place.

I found in period pictures and modern day walkarounds that the main bolt holding each roadwheel on is often secured with a strap held on by two opposing lug nuts. The RSO probably came from the factory this way. I decided my RSO should have this feature.

I wanted to simply put a strip of brass with two holes over the lug nuts, but this wasn't practical. My only other choice was to remove two lug nuts, superglue a strip of brass on, and reattach the lug nuts with superglue. To this end I sliced two lug nuts off each roadwheel with a fresh #11 blade (with tape over the nuts to keep them away from the carpet monster).

Then I pulled off the tape taking the two nuts with it. I shaved off the remaining plastic left behind so the brass strip would be tight against the wheel. Not shown is how I cut a strip of brass, pressed it over the hub of the wheel, and cut it to length. Some of the wheels got scored in the process, so a bit of putty was required to cover up the damage.

And here are all eight roadwheels modified with the brass strip and the lug nuts reattached. Comparing my work to photos of the RSO, I made the strips a little too wide, but I'm just glad the carpet monster didn't get any of the lug nuts. They are practically microscopic!
